ATEN HDMI HDBaseT Receiver with Dual Output (4K@100m) (HDBaseT Class A)
- Extends HDMI signals to one local and two remote displays up to 100 m over a single Cat 5e/6/6a or ATEN 2L-2910 Cat 6 cable
- HDMI (3D, Deep Color, 4K); HDCP 2.2 compatible
- Extends Ethernet communication using the Ethernet pass-through port*
- Supports two IR channels for simultaneous IR signal transmissions, ranged from 30 KHz to 56 KHz
- ATEN EDID Technology — when both transmitter and receiver sides are connected, VE814A adopts the EDID values of the display connected to the VE814AT for high-quality output
- RS-232 channel – allows you to connect to serial terminals or serial devices, such as touch screens and barcode scanners
- Supports wide screen format
- Built-in 8 kV/15 kV ESD protection
- Plug-and-play
- Rack-mountable
ATEN VE814AR is an HDBaseT Video Receiver that is capable of receiving HDMI signals up to 100 m over a single Cat 5e/6/6a or ATEN 2L-2910 Cat 6 cable.This HDCP 2.2-compliant receiver meets the HDMI Specification, including 3D, Deep Color, the maximum data rate of (10.2 Gbps), and 4K video quality up to 100 m.
The VE814AR supports RS-232 and IR signaling pass-through, allowing you to control the HDMI source device from the remote unit (VE814AR) while granting access to the HDMI display device from the local unit (VE814AT). In addition, it supports Long Reach Mode that extends HDMI signals up to 150 m, 1080p, via a single Cat 5e/6 cable.
The VE814AR is a powerful solution for where digital signage is required, such as bars, educational spaces, and public transportation stations, allowing display of identical contents at different spots.
| Features | |
|---|---|
| Product colour | Black |
| Firmware upgradeable | Yes |
| HDCP | Yes |
| HDCP version | 2.2 |
| 3D | Yes |
| Baud rate | 57.6 Kbit/s |
| Impedance | 100 Ω |
| Consumer Electronics Control (CEC) support | Yes |
| Supported graphics resolutions | 1920 x 1080 (HD 1080), 3840 x 2160, 4096 x 2160 |
| Material | Metal |
| Bandwidth | 10.2 Gbit/s |
| Infrared (IR) frequency range | 30 – 56 kHz |
| Maximum refresh rate | 60 Hz |
| Maximum transfer distance | 150 m |
| Cable types supported | Cat5e, Cat6, Cat6a |
| Maximum resolution | 4096 x 2160 pixels |
| Type | AV receiver |
| Ports & interfaces | |
|---|---|
| DC-in jack | Yes |
| Serial interface type | RS-232 |
| Remote (IR) input | 1 |
| Remote (IR) output | 1 |
| Serial ports quantity | 1 |
| Number of HDMI outputs | 2 |
| HDBaseT port | Yes |
| RJ-45 input ports | 1 |
| Ethernet LAN | No |
| Connectivity technology | Wired |
| Power | |
|---|---|
| Operating voltage | 5 V |
| Operational conditions | |
|---|---|
| Operating temperature (T-T) | 0 – 40 °C |
| Storage temperature (T-T) | -20 – 60 °C |
| Operating relative humidity (H-H) | 0 – 80% |
| Weight & dimensions | |
|---|---|
| Weight | 470 g |
| Height | 30 mm |
| Depth | 140.2 mm |
| Width | 123 mm |
| Packaging data | |
|---|---|
| Package weight | 760 g |
| Package height | 160 mm |
| Package depth | 239 mm |
| Package width | 59 mm |
| Packaging content | |
|---|---|
| Manual | Yes |
| AC adapter included | Yes |
| Technical details | |
|---|---|
| Package volume | 2265.35 cm³ |
| Country of origin | Taiwan |
| Logistics data | |
|---|---|
| Master (outer) case net weight | 3.05 kg |
| Master (outer) case volume | 14158.42 cm³ |
| Master (outer) case gross weight | 4.15 kg |
| Master (outer) case height | 175 mm |
| Master (outer) case length | 325 mm |
| Master (outer) case width | 250 mm |
