Ubiquiti U7 Outdoor 4300 Mbit/s White Power over Ethernet (PoE)
- WiFi 7
- 4 spatial streams
- 465 m² (5,000 ft²) open space coverage with the integrated directional super antenna
- Software-adjustable antenna beamwidth for balanced coverage with the included omni antennas
- 200+ connected devices
- Powered using PoE+
- 2.5 GbE uplink
- Versatile wall and pole mounting
- Weatherproof (outdoor exposed)
All-weather WiFi 7 AP with 4 spatial streams, an integrated directional super antenna, and versatile mounting options.
| Features |
| Quality of Service (QoS) support |
Yes |
| Rate limiting |
Yes |
| VLAN support |
Yes |
| Spatial streams |
4 |
| MIMO type |
Multi User MIMO |
| MIMO |
Yes |
| Networking standards |
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11be, IEEE 802.11g, IEEE 802.11n, IEEE 802.1Q, IEEE 802.3at |
| Frequency band |
2.4 – 5 GHz |
| Throughput data rate |
4324 Mbit/s |
| Ethernet LAN data rates |
2500 Mbit/s |
| Maximum data transfer rate |
4300 Mbit/s |
| 5 GHz |
Yes |
| 6 GHz |
No |
| 2.4 GHz |
Yes |
| Security |
| Security algorithms |
PPSK, WPA, WPA-Enterprise, WPA-PSK, WPA2, WPA3 |
| Ports & interfaces |
| Ethernet LAN (RJ-45) ports |
1 |
| Power |
| Power consumption (max) |
19 W |
| DC voltage range |
44 – 57 V |
| Power over Ethernet (PoE) |
Yes |
| Design |
| Recommended usage |
Outdoor |
| LED indicators |
Yes |
| Reset button |
Yes |
| International Protection (IP) code |
IPX6 |
| Housing material |
Aluminium, Polycarbonate (PC) |
| Product colour |
White |
| Placement |
Ceiling, Pole, Wall |
| Antenna |
| Number of connectors |
2 |
| Antenna connector type |
RP-SMA |
| Antenna gain level (max) |
12.5 dBi |
| Antennas quantity |
2 |
| Antenna features |
Detachable antenna |
| Antenna direction type |
Omni-directional |
| Antenna type |
External |
| Certificates |
| Compliance certificates |
CE, Federal Communications Commission (FCC), Industry Canada (IC) |
| Weight & dimensions |
| Weight |
1.2 kg |
| Height |
208 mm |
| Depth |
54.5 mm |
| Width |
170 mm |
| Packaging content |
| Mounting kit |
Yes |
| Quantity per pack |
1 pc(s) |
| Operational conditions |
| Operating temperature (T-T) |
-30 – 60 °C |
| Operating relative humidity (H-H) |
5 – 95% |
| Sustainability |
| Sustainability compliance |
Yes |
