TP-Link Archer C2300 wireless router Gigabit Ethernet Dual-band (2.4 GHz / 5 GHz) Black
- Watch 4K movies and game with high-speed AC2300 dual-band Wi-Fi
- Powerful 1.8GHz dual-core 64-bit CPU with two co-processors deliver smooth and speedy connections
- RangeBoost and beamforming greatly improve Wi-Fi connection to devices located farther away
- MU-MIMO** connects more Wi-Fi devices at once for faster performance
- Airtime Fairness equally divides attention between newer and older devices to improve Wi-Fi performance
- A free lifetime subscription of TP-Link HomeCareTM protects against the latest threats with powerful security and antivirus
Wave 2 AC Wi-Fi for More Bandwidth
With NitroQAM Technology, Archer C2300 boosts the Wi-Fi Speed up to 1625Mbps on 5GHz and
600Mbps on 2.4GHz. It can perfectly handle your favorite activities like gaming online, watching
4K movies, or sharing large files.
64-Bit CPU and XStream Processing for Smoother Performance
With XStream processor architecture, the Archer C2300 dedicates one processor to each of its Wi-Fi bands. These processors handle Wi-Fi traffic, freeing the router’s powerful 1.8 GHz dual-core 64-bit CPU to take care of everything else.
MU-MIMO and Smart Connect for Better Connections
MU-MIMO lets the Archer C2300 talk to several devices at once, and Smart Connect automatically places each device on the best available Wi-Fi band. With both working together, everyone can hop online at the same time without having to wait, and each device can always get the best connection.
RangeBoost for Far-Reaching Wi-Fi
RangeBoost amplifies the router’s ability to detect and receive Wi-Fi signal from devices that are located farther away. Stream, game and enjoy what you love anywhere in your home, from your favorite spot on the couch to the comfort of your bed.
Media Sharing for More Fun
USB 3.0 and 2.0 ports make it easy to share photos, videos, and music on your home network.
When away from home, a VPN allows you to securely access NAS drives and other devices connected to the router through USB.
VPN Acceleration for Fast and Stable VPN
Archer C2300 is not only supporting safe and secure OpenVPN and PPTP VPN connection, but also using VPN Acceleration to boost the connection speed. All of the data you’re transmitting is guaranteed to be secured by these VPN functions.
Intuitive Tether App for Easy Management
Setup and manage your Wi-Fi through the free TP-Link Tether app, available for both Android and iOS. Tether’s simple layout lets you quickly access all of your Wi-Fi settings on your phone or tablet.
HomeCare for Protection, Safety and Fast Wi-Fi
You don’t need to buy a separate security box device like Cujo or Circle to add security to your network. A free lifetime subscription of TP-Link HomeCareTM comes with antivirus, parental controls and QoS
Antivirus
Every device that uses Wi-Fi is protected by HomeCareTM. That includes things that don’t normally have protection from cyber threats, like Wi-Fi cameras, smart locks and game consoles. It even protects devices that your friends use at your home.
Parental Controls
Whether you want to block websites, set time limits, see which sites your kids are using or pause the internet, you can with HomeCareTM. And you can do it all from the Tether app.
Prioritize What Matters
Choose which devices or activities you want to prioritize with Quality of Service (QoS). In just a few taps, you can make sure your laptop or streaming movie is first in line for Wi-Fi or Ethernet.
| WAN connection | |
|---|---|
| WAN connection type | RJ-45 |
| 3G/4G USB modem compatibility | No |
| SIM card slot | No |
| DSL WAN | Yes |
| Ethernet WAN | Yes |
| Wireless LAN features | |
|---|---|
| WLAN data transfer rate (second band) | 1733 Mbit/s |
| WLAN data transfer rate (first band) | 600 Mbit/s |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| WLAN data transfer rate (max) | 1733 Mbit/s |
| Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
| Wi-Fi band | Dual-band (2.4 GHz / 5 GHz) |
| Network | |
|---|---|
| Receiver sensitivity | 5GHz:11ac80M MCS11: -58dBm, 11ac80M MCS0: -88dBm11ac40M MCS11: -61dBm, 11ac40M MCS0: -91dBm11ac20M MCS11: -63dBm, 11ac20M MCS0: -95dBm54M: -76dBm, 6M: -95dBm2.4GHz:11n40M MCS9: -63dBm, 11n40M MCS0: -89dBm11n20M MCS8: -67dBm, 11n20M MCS0: -92dBm54M: -75dBm, 11M : -90dBm, 6M: -93dBm, 1M: -98dBm |
| Dynamic DNS (DDNS) | Yes |
| Port forwarding | Yes |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Cabling technology | 10/100/1000Base-T(X) |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Ethernet LAN interface type | Gigabit Ethernet |
| Ethernet LAN | Yes |
| Mobile network | |
|---|---|
| 3G | No |
| 4G | No |
| Ports & interfaces | |
|---|---|
| DC-in jack | Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| USB 2.0 ports quantity | 1 |
| USB port | Yes |
| Ethernet LAN (RJ-45) ports | 4 |
| Management features | |
|---|---|
| WPS push button | Yes |
| Reset button | Yes |
| Quality of Service (QoS) support | Yes |
| Security | |
|---|---|
| DMZ support | Yes |
| Port-based Network Access Control (PNAC) | Yes |
| Guest access | Yes |
| Firewall security | DoS, SPI Firewall, IP and MAC Address Binding |
| Firewall | Yes |
| Security algorithms | 64-bit WEP, 128-bit WEP, WEP, WPA, WPA-PSK, WPA2 |
| Protocols | |
|---|---|
| Supported network protocols | IPv4, IPv6 |
| Universal Plug and Play (UPnP) | Yes |
| DHCP server | Yes |
| DHCP client | Yes |
| Design | |
|---|---|
| On/off switch | Yes |
| LED indicators | LAN, Power, Status, System, WAN, WLAN |
| Product colour | Black |
| Product type | Tabletop router |
| Packaging content | |
|---|---|
| Quick installation guide | Yes |
| AC adapter included | Yes |
| Cables included | LAN (RJ-45) |
| Certificates | |
|---|---|
| Certification | CE, FCC, RoHS |
| Antenna | |
|---|---|
| Transmit power | 2.4G≤30dBm, 5G≤30dBm |
| Detachable antenna(s) | Yes |
| Antenna gain level (max) | 3 dBi |
| Antenna design | External |
| Features | |
|---|---|
| Flash memory | 128 MB |
| Internal memory | 256 MB |
| Processor cores | 2 |
| Processor frequency | 1800 MHz |
| Built-in processor | Yes |
| Power | |
|---|---|
| Output current | 2 A |
| Output voltage | 12 V |
| Power source type | DC |
| Operational conditions | |
|---|---|
| Operating temperature (T-T) | 0 – 40 °C |
| Storage temperature (T-T) | -40 – 90 °C |
| Operating relative humidity (H-H) | 10 – 90% |
| Storage relative humidity (H-H) | 5 – 90% |
| Weight & dimensions | |
|---|---|
| Width | 216 mm |
| Depth | 164 mm |
| Height | 36.8 mm |
| Packaging data | |
|---|---|
| Package type | Box |
| Logistics data | |
|---|---|
| Harmonized System (HS) code | 85176990 |
| Other features | |
|---|---|
| Maximum data transfer rate | 1 Mbit/s |
