TieDex UK Yealink MeetingBar A10
Yealink MeetingBar A10 – All-in-One video collaboration bar (video bar, VCR11 remote control) – Certified for Microsoft Teams, Certified for Zoom Rooms
Basic Specifications
- Manufacturer’s Part Number
- A10-010
- EAN
- 6938818312418
- Networking
- Network adapter – Ethernet, Fast Ethernet, Gigabit Ethernet, Wi-Fi, Bluetooth 4.2
- Video Input
- Digital video camera
- Video Output
- Codec board
- Codec
- H.264, H.264 High Profile, H.264 SVC
- Power
- AC 100-240 V
- Model
- Yealink MeetingBar A10
- Device Type
- All-in-One video collaboration bar
- Input Device
- Remote control
- Audio Output
- Speaker(s) – stereo
- Product Description
- Yealink MeetingBar A10
- Audio Input
- 8-microphone array – MEMS-directional
- Software Certification
- Certified for Microsoft Teams, Certified for Zoom Rooms
- Kit Content
- Video bar, VCR11 remote control
Video Output
- Type
- Codec board – integrated
- Digital Video Standard
- High-Definition Multimedia Interface (HDMI)
Networking
- Type
- Network adapter
- Connectivity Technology
- Wireless, wired
- Data Link Protocol
- Ethernet, Fast Ethernet, Gigabit Ethernet, Wi-Fi, Bluetooth 4.2
- Network / Transport Protocol
- DHCP, HTTP, HTTPs, IPv4, IPv6
- Features
- VLAN support, Quality of Service (QoS), static IP mode, LLDP support, content sharing, Yealink Noise Proof Technology, electronic privacy shutter
- Compliant Standards
- IEEE 802.1Q, IEEE 802.1p, IEEE 802.1x
Expansion / Connectivity
- Interfaces
- 1 x audio / video – HDMI output – 19 pin HDMI Type A ¦ 1 x network – Ethernet 10Base-T/100Base-TX/1000Base-T – RJ-45 ¦ 1 x USB 2.0 – 4 pin USB Type A ¦ 1 x Yealink VCH port – RJ-45 ¦ 1 x USB-C – 24 pin USB-C
Video Input
- Type
- Digital video camera (colour) – integrated
- Video Modes
- 1080/30p, 720/30p
- Features
- ePTZ, Auto Object Framing, 120° field of view, speaker tracking, AI Tracking
- Angular Field Of View (max, degree)
- 120
Power
- Power Device
- Power adapter – external
- Voltage Required
- AC 100-240 V
- Power Consumption Operational
- 10.5 Watt
Environmental Parameters
- Min Operating Temperature
- 0 °C
- Max Operating Temperature
- 40 °C
- Humidity Range Operating
- 10 – 95%
General
- Device Type
- All-in-One video collaboration bar
- Kit Content
- Video bar, VCR11 remote control
- Video Codecs
- H.264, H.264 High Profile, H.264 SVC
- Quality of Service
- IEEE 802.1Q (VLAN), Differentiated Services (DiffServ), IEEE 802.1p
- IP Address Assignment
- DHCP
- Security
- 256 bit AES, EAP-MD5, IEEE 802.1X, EAP-TLS, EAP-TTLS, TLS 1.2, PEAP-MSCHAPv2, EAP-MSCHAPv2, TLS 1.3
- Network Protocols
- HTTP, HTTPS, Link Layer Discovery Protocol (LLDP), TLS
- Dimensions & Weight Details
- Video bar – Width 38 cm Depth 6.8 cm Height 8.2 cm
- Built-in Devices
- Dual 5 W speakers, 8 microphone array, 4K webcam
Miscellaneous
- Cables Included
- 1 x network cable – 3 m ¦ 1 x HDMI cable – 1.8 m
- Included Accessories
- Mounting bracket
- Software Certification
- Certified for Microsoft Teams, Certified for Zoom Rooms
- Compliant Standards
- ISO 9001, NOM, CCC, FCC, RoHS, ANATEL, REACH, CEC, RCM
Software / System Requirements
- Software Included
- Android 11
Input Device
- Type
- Remote control
Audio Output
- Type
- Speaker(s)
- Output Power / Channel
- 5 Watt
- Sound Output Mode
- Stereo
Audio Input
- Type
- 8-microphone array – integrated
- Microphone Operation Mode
- MEMS-directional
