TieDex UK TP-Link TX401 – V1 – network adapter – PCIe 3.0 x4 – 1/2.5/5/10GBase-T x 1
TP-Link TX401 – V1 – network adapter – PCIe 3.0 x4 low profile – 1/2.5/5/10GBase-T x 1
Basic Specifications
- Manufacturer’s Part Number
- TX401
- EAN
- 6935364072834
- Product Description
- TP-Link TX401 – V1 – network adapter – PCIe 3.0 x4 – 1/2.5/5/10GBase-T x 1
- Model
- TP-Link TX401
- Dimensions (WxDxH)
- 2.15 cm x 12.08 cm x 9.82 cm
- Device Type
- Network adapter
- Compliant Standards
- IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3an, IEEE 802.3az, IEEE 802.3bz
- Form Factor
- Plug-in card – low profile
- System Requirements
- Linux, Microsoft Windows 7 / 8 / 8.1 / 10, Microsoft Windows Server 2019
- Data Link Protocol
- 10GbE
- Ports
- 1/2.5/5/10GBase-T x 1
- Cabling Type
- Ethernet 100Base-TX, Ethernet 1000Base-T, Ethernet 10GBase-T, Ethernet 2.5GBase-T, Ethernet 5GBase-T
- Interface (Bus) Type
- PCI Express 3.0 x4
General
- Device Type
- Network adapter
- Form Factor
- Plug-in card – low profile
- Interface (Bus) Type
- PCI Express 3.0 x4
Dimensions & Weight
- Width
- 2.15 cm
- Depth
- 12.08 cm
- Height
- 9.82 cm
Miscellaneous
- Included Accessories
- Low-profile bracket
- Cables Included
- 1 x network cable (external) – 1.5 m
- Compliant Standards
- FCC, RoHS
Networking
- Ports
- 1/2.5/5/10GBase-T x 1
- Connectivity Technology
- Wired
- Cabling Type
- Ethernet 100Base-TX, Ethernet 1000Base-T, Ethernet 10GBase-T, Ethernet 2.5GBase-T, Ethernet 5GBase-T
- Data Link Protocol
- 10 Gigabit Ethernet
- Status Indicators
- Link/activity
- Features
- Auto-negotiation, half duplex mode, full duplex mode, QoS
- Compliant Standards
- IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3an, IEEE 802.3az, IEEE 802.3bz
Expansion / Connectivity
- Interfaces
- 1 x 1/2.5/5/10GBase-T – RJ-45
Environmental Parameters
- Min Operating Temperature
- 0 °C
- Max Operating Temperature
- 40 °C
- Humidity Range Operating
- 10 – 90% (non-condensing)
Software / System Requirements
- Software Included
- Drivers & Utilities
- OS Required
- Linux, Microsoft Windows 7 / 8 / 8.1 / 10, Microsoft Windows Server 2019
