TieDex UK TP-Link Omada EAP653 V1 – radio access point – Wi-Fi 6 – cloud-managed
TP-Link Omada EAP653 V1 – Radio access point – Wi-Fi 6 – 2.4 GHz, 5 GHz – DC power – cloud-managed – wall / ceiling mountable
Basic Specifications
- Manufacturer’s Part Number
- EAP653
- EAN
- 4897098685242
- Product Description
- TP-Link Omada EAP653 V1 – radio access point – Wi-Fi 6 – cloud-managed
- Model
- TP-Link Omada EAP653 V1
- Dimensions (WxDxH)
- 16 cm x 16 cm x 3.36 cm
- Power
- DC 12 V
- Device Type
- Radio access point
- Capacity
- Maximum number of configured SSIDs: 16 ¦ Number of concurrent clients: 250+
- Form Factor
- Wall / ceiling mountable
- Performance
- Maximum data rate (2.4 GHz): 574 Mbps ¦ Maximum data rate (5 GHz): 2402 Mbps ¦ Bandwidth: 160 MHz
- Frequency Band
- 2.4 GHz, 5 GHz
- Data Link Protocol
- IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6)
- OS Required
- Linux, Windows 8, Microsoft Windows XP / Vista / 7 / 10 / 11
- Power Over Ethernet (PoE) Supported
- PoE+
- Included Accessories
- Wall/ceiling mounting kit
General
- Device Type
- Radio access point
- Width
- 16 cm
- Depth
- 16 cm
- Height
- 3.36 cm
Miscellaneous
- Included Accessories
- Wall/ceiling mounting kit
- Compliant Standards
- FCC, RoHS
Networking
- Form Factor
- Wall / ceiling mountable
- Connectivity Technology
- Wireless
- Line Coding Format
- OFDM, 1024 QAM, OFDMA
- Data Link Protocol
- IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6)
- Spread Spectrum Method
- OFDM, OFDMA
- Remote Management Protocol
- SNMP 1, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, SSH, NTP
- Cloud-Managed
- Yes
- Frequency Band
- 2.4 GHz, 5 GHz
- Performance
- Maximum data rate (2.4 GHz): 574 Mbps ¦ Maximum data rate (5 GHz): 2402 Mbps ¦ Bandwidth: 160 MHz
- Capacity
- Maximum number of configured SSIDs: 16 ¦ Number of concurrent clients: 250+
- Wi-Fi Rating
- AX3000
- Status Indicators
- Status
- Features
- Load balancing, VLAN support, Syslog support, E-mail alert, MAC address filtering, Wi-Fi Multimedia (WMM) support, Access Control List (ACL) support, Quality of Service (QoS), reset button, Captive Portal, Transmit Power Control (TPC), MU-MIMO technology, beamforming technology, band steering, SSID to VLAN mapping, rate limit, Wireless Scheduler, wireless SSID, LED on/off button, seamless roaming, Airtime Fairness, Zero-touch provisioning (ZTP), adjustable transmission power, schedule reboot, self-healing network, Omada Mesh technology, multi-site management
- Encryption Algorithm
- WPA-Enterprise, WPA2-Enterprise, WPA3-Enterprise, WPA3-Personal, WPA2-Personal, WPA-Personal
- Authentication Method
- Secure Shell (SSH), Radio Service Set ID (SSID)
- Compliant Standards
- IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.1x, IEEE 802.11n, IEEE 802.3at, IEEE 802.11ac, IEEE 802.11ax, Wi-Fi CERTIFIED 6
Expansion / Connectivity
- Interfaces
- 1 x 1000Base-T (PoE+) – RJ-45
Power
- Power Over Ethernet (PoE) Supported
- PoE+
- Power Device
- External power adapter
- Voltage Required
- DC 12 V
- Power Consumption Operational
- 14.7 Watt
Environmental Parameters
- Min Operating Temperature
- 0 °C
- Max Operating Temperature
- 40 °C
- Humidity Range Operating
- 10 – 90% RH (non-condensing)
Software / System Requirements
- Software Included
- Omada Controller
- OS Required
- Linux, Windows 8, Microsoft Windows XP / Vista / 7 / 10 / 11
Aerial
- Antenna
- Internal
- Directivity
- Omni-directional
