TieDex UK Draytek Vigor 3912 – Enterprise – router – 802.1x
Draytek Vigor 3912 – Enterprise – router 1GbE, 12.5GbE – 802.1x
Basic Specifications
- Manufacturer’s Part Number
- V3912-K
- EAN
- 4710484747013
- Manufacturer Warranty
- 2-year warranty
- Weight
- 3.76 kg
- Product Description
- Draytek Vigor 3912 – Enterprise – router – 802.1x
- Model
- Draytek Vigor 3912
- Dimensions (WxDxH)
- 44.3 cm x 28.5 cm x 4.5 cm
- Localisation
- United Kingdom, Ireland
- Features
- Load balancing, DrayDDNS, DHCP server, PPPoE server, DNS server, DNSSEC support, IP multicast, policy based routing, port mirroring, RADIUS Server, IGMP proxy, SMS alert, E-mail alert, QoS, VoIP support
- Power
- AC 100-240 V (50/60 Hz)
- Device Type
- Router
- Compliant Standards
- IEEE 802.1p, IEEE 802.1Q
- Capacity
- NAT sessions: 1000 ¦ Concurrent VPN tunnels: 500 ¦ Concurrent SSL VPN tunnels: 200
- Performance
- NAT throughput: 12.5 Gbps ¦ VPN throughput (IPSec): 5000 Mbps ¦ VPN throughput (SSL): 3500 Mbps ¦ VPN WireGuard throughput: 900 Mbps
- Data Link Protocol
- Ethernet, Fast Ethernet, Gigabit Ethernet, 12.5 Gigabit Ethernet
- Enclosure Type
- – 1U
- Network / Transport Protocol
- PPPoE, DHCP, IPv4, IPv6, DHCPv6, Bonjour, IPSec, L2TP, PPTP
- Remote Management Protocol
- SNMP 1, SNMP 2c, SNMP 3
General
- Device Type
- Router
- Enclosure Type
- – 1U
- Connectivity Technology
- Wired
- Data Link Protocol
- Ethernet, Fast Ethernet, Gigabit Ethernet, 12.5 Gigabit Ethernet
- Performance
- NAT throughput: 12.5 Gbps ¦ VPN throughput (IPSec): 5000 Mbps ¦ VPN throughput (SSL): 3500 Mbps ¦ VPN WireGuard throughput: 900 Mbps
- Capacity
- NAT sessions: 1000 ¦ Concurrent VPN tunnels: 500 ¦ Concurrent SSL VPN tunnels: 200
- Network / Transport Protocol
- PPPoE, DHCP, IPv4, IPv6, DHCPv6, Bonjour, IPSec, L2TP, PPTP
- Remote Management Protocol
- SNMP 1, SNMP 2c, SNMP 3
- Encryption Algorithm
- IKEv1, IKEv2, SSL, SHA-512, SHA-256, MD5
- Authentication Method
- RADIUS, LDAP, TACACS+, Time-based One Time Password (TOTP), Mobile One Time Password (mOTP), X.509 certificates, Extensible Authentication Protocol (EAP)
- Features
- Load balancing, DrayDDNS, DHCP server, PPPoE server, DNS server, DNSSEC support, IP multicast, policy based routing, port mirroring, RADIUS Server, IGMP proxy, SMS alert, E-mail alert, QoS, VoIP support
- Compliant Standards
- IEEE 802.1p, IEEE 802.1Q
Dimensions & Weight
- Width
- 44.3 cm
- Depth
- 28.5 cm
- Height
- 4.5 cm
- Weight
- 3.76 kg
Miscellaneous
- Included Accessories
- RJ11 to RS-232 converter
- Cables Included
- 1 x network cable ¦ 1 x serial cable ¦ 1 x power cable (C13)
- Rack Mounting Kit
- Included
- Localisation
- United Kingdom, Ireland
Manufacturer Warranty
- Service & Support
- Limited warranty – 2 years
Expansion / Connectivity
- Interfaces
- WAN / LAN: 8 x 10GBase-T – SFP+ ¦ WAN / LAN: 2 x 2.5G Gigabit Ethernet – RJ-45 ¦ WAN / LAN: 4 x 10/100/1G Ethernet – RJ-45 ¦ LAN: 4 x 10/100/1G Ethernet ¦ USB 3.0: 2 x 4 pin USB Type A ¦ Serial: 1 x RJ-45
Power
- Power Device
- External power adapter
- Voltage Required
- AC 100-240 V (50/60 Hz)
- Power Consumption Operational
- 35 Watt
Environmental Parameters
- Min Operating Temperature
- 0 °C
- Max Operating Temperature
- 45 °C
- Humidity Range Operating
- 10 – 90% (non-condensing)
