StarTech.com Desk Mount Dual Monitor Arm – Ergonomic Dual Monitor VESA Mount 32″ (17.6lb) Displays – Crossbar Handle for Synchronized Full Motion – Height Adjustable – C-Clamp/Grommet
- DUAL 32 INCH MONITOR ARM: VESA 75×75/100x100mm compatible heavy-duty desk mount dual monitor arm supports large monitors up to 32″ (17.6lb/8kg) per display w/ synchronized full motion articulation
- ONE-TOUCH ADJUSTMENT: Max height of 23.4″ from desk, the spring-assisted computer monitor arm w/sturdy handle offers synchronized toolless adjustable height range of 13″ & can extend outward up to 23″
- WIDE RANGE OF MOTION: Ergonomic monitor arm increases comfort w/ individual monitor +/-10° tilt, +/-10° swivel, 360° rotating; sliding horizontal crossbar for screen alignment can also swivel 180°
- EASY INSTALLATION: C-clamp or grommet mount secures to desk (10mm to 48mm); detachable VESA plate w/ quick release clip makes mounting displays easy; tools incl. to adjust articulating tension
- SMALL FOOTPRINT: Universal desktop multi-monitor mount w/space-saving design enhances the work area & built-in adjustable cable management channels along the arms w/ covers keep cables organized
Adjustable Dual Monitor Mount | Synced Height Adjustment | Easy-Grip Handle
This Dual Monitor Arm lets you mount two 17″ to 32″ VESA mount monitors, each weighing up to 17.6 lb. (8 kg), onto a single low-profile base. It gives you flexible desk-clamp or grommet-hole mounting, letting you save space while creating an ergonomic workspace in any office environment.
Free Up Desk Space
With a stable crossbar design, the adjustable height dual monitor stand lets you create more usable work space by mounting your monitors side by side on a single base.
Optimal Viewing
The computer screen stand features one-touch height adjustment. The smooth +/- 10° tilt motion and +/- 10° swivel of the individual monitors make it easy to find the optimal viewing angle. You can also rotate each display 360° for portrait or landscape viewing and laterally adjusted along the crossbar length.
Flexible Installation
The adjustable dual monitor mount is easy to install, with the desk-clamp or grommet mount (hardware included). Integrated cable management keeps your workspace organized. It works well with most desks, including sit-stand workstations.
The Choice of IT Pros Since 1985
StarTech.com conducts thorough compatibility and performance testing on all our products to ensure we are meeting or exceeding industry standards and providing high-quality products to IT Professionals. Our local StarTech.com Technical Advisors have broad product expertise and work directly with our StarTech.com Engineers to provide support for our customers both pre and post-sales.
ARMSLMBARDUO is backed by a 5-year StarTech.com warranty and free lifetime technical support.
The StarTech.com Advantage
– DUAL 32 INCH MONITOR ARM: VESA 75×75/100x100mm compatible heavy-duty desk mount dual monitor arm supports large monitors up to 32″ (17.6lb/8kg) per display w/ synchronized full motion articulation
– ONE-TOUCH ADJUSTMENT: Max height of 23.4″ from desk, the spring-assisted computer monitor arm w/sturdy handle offers synchronized toolless adjustable height range of 13″ & can extend outward up to 23″
– WIDE RANGE OF MOTION: Ergonomic monitor arm increases comfort w/ individual monitor +/-10° tilt, +/-10° swivel, 360° rotating; sliding horizontal crossbar for screen alignment can also swivel 180°
| Mounting | |
|---|---|
| Desk thickness (max) | 8.5 cm |
| Desk thickness (min) | 1 cm |
| Number of displays supported | 2 |
| Maximum VESA mount | 100 x 100 mm |
| Minimum VESA mount | 75 x 75 mm |
| Mounting | Clamp |
| Mounting type | Desk |
| Maximum screen size | 81.3 cm (32″) |
| Minimum screen size | 43.2 cm (17″) |
| Maximum weight capacity | 16 kg |
| Ergonomics | |
|---|---|
| Angle of rotation | 180° |
| Swivel angle | 90° |
| Tilt angle range | -10 – 10° |
| Height adjustment | Yes |
| Design | |
|---|---|
| Housing material | Steel |
| Product colour | Black |
| Weight & dimensions | |
|---|---|
| Weight | 7.3 kg |
| Height | 600 mm |
| Depth | 830 mm |
| Width | 570 mm |
| Packaging data | |
|---|---|
| Package weight | 8.8 kg |
| Package height | 150 mm |
| Package depth | 900 mm |
| Package width | 220 mm |
| Packaging content | |
|---|---|
| Grommet plate included | Yes |
| Grommet base plate included | Yes |
| Number of washers included | 8 |
| Number of screws | 27 |
| Screws included | Yes |
| Mounting brackets included | Yes |
| Number of cable clips | 1 |
| VESA mount included | Yes |
| Wrench type | Hexagonal wrench |
| Wrench included | Yes |
| Other features | |
|---|---|
| Certification | CE, REACH |
| Compliance certificates | RoHS |
| Logistics data | |
|---|---|
| Harmonized System (HS) code | 85299097 |
| Master (outer) case height | 170 mm |
| Master (outer) case length | 915 mm |
| Master (outer) case width | 470 mm |
