Sharp PN-L752B interactive whiteboard 190.5 cm (75″) 3840 x 2160 pixels Touchscreen Black
- Pen-On-Paper user experience – Zero Bonding and Sharp’s PrecisionTouch technology enable highly accurate and responsive writing and drawing with up to 20 touch points
- Out-of-the-box collaboration – the integrated Android PC features a powerful home screen launcher offering fast and flexible access to a range of pre-installed applications
- Latest BYOD wireless collaboration – wirelessly share content from any device via the integrated Android PC or utilise the OPS slot to extend the BIG PADs functionality with third-party add-ons and solutions
- Maximum flexibility – provides exceptional freedom of use to meet the demands of even the most challenging corporate environments using USB-C, HDMI or VGA connectors
- ‘Secure by design’ – graded data security allows to adjust the level of security of the Android PC and maintain protection at the security level you need
Enjoy a more natural way of working
The BIG PAD L2B range of smart interactive displays combines genuine ‘4K reading and writing’ and an intuitive ‘Pen-on-Paper’ user experience with Zero Bonding and Sharp’s PrecisionTouch technology. The single USB-C connector makes it so simple to walk into a room, plug in your device and start working together straightaway. The L2B series also features an integrated Android PC with whiteboard, overlay writing mode and wireless screen sharing functionality as well as graded security to help enhance your productivity.
The BIG PAD L2B series is the perfect choice for busy office environments, boardrooms, meeting rooms and training sessions that require quick responsive operation and smart integrated collaboration tools. It encourages effective group teamwork, promotes idea sharing and helps people deliver great presentations and achieve better meeting outcomes.
| Display |
| Hardness |
8H |
| Haze rate |
8% |
| Screen glass thickness |
3.4 mm |
| Viewing angle, horizontal |
178° |
| Viewing angle, vertical |
178° |
| Number of simultaneous touchpoints |
20 |
| Touch technology |
Multi-touch |
| Touchscreen |
Yes |
| Response time |
8.5 ms |
| Contrast ratio (typical) |
5000:1 |
| Native aspect ratio |
16:9 |
| LED backlighting type |
Direct-LED |
| Panel type |
IPS |
| HD type |
4K Ultra HD |
| Display resolution |
3840 x 2160 pixels |
| Display brightness |
350 cd/m² |
| Display diagonal |
190.5 cm (75″) |
| Computer system |
| RAM capacity |
4 GB |
| User memory |
32 GB |
| Processor architecture |
ARM Cortex-A73 |
| Built-in processor |
Yes |
| Operating system version |
9 |
| Operating system installed |
Android |
| Audio |
| Speaker power |
20 W |
| Number of built-in speakers |
2 |
| Built-in speaker(s) |
Yes |
| Projector |
| Built-in projector |
No |
| Network |
| Ethernet LAN data rates |
10,100 Mbit/s |
| Ethernet LAN |
Yes |
| Bluetooth |
Yes |
| Bluetooth version |
5.0 |
| Top Wi-Fi standard |
Wi-Fi 5 (802.11ac) |
| Wi-Fi |
Yes |
| Ports & interfaces |
| RS-232 ports |
1 |
| Headphone connectivity |
3.5 mm |
| Audio output |
1 |
| VGA (D-Sub) ports quantity |
1 |
| Ethernet LAN (RJ-45) ports |
1 |
| USB Type-C ports quantity |
1 |
| HDMI ports quantity |
3 |
| USB 2.0 ports quantity |
1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
4 |
| Ergonomics |
| Certification |
CE; FCC; RCM; REACH; RoHS; UL/C-UL |
| Product colour |
Black |
| Power |
| AC input voltage |
100 – 240 V |
| AC input frequency |
50 – 60 Hz |
| Power consumption (standby) |
0.5 W |
| Power consumption (max) |
400 W |
| System requirements |
| Mobile operating systems supported |
Android 9.0 |
| Linux operating systems supported |
Yes |
| Windows operating systems supported |
Windows 10, Windows 11, Windows 8.1 |
| Mac compatibility |
Yes |
| Operational conditions |
| Operating relative humidity (H-H) |
20 – 80% |
| Operating temperature (T-T) |
5 – 35 °C |
| Weight & dimensions |
| Weight |
49.5 kg |
| Height |
1019.8 mm |
| Depth |
85.7 mm |
| Width |
1709.4 mm |
| Packaging data |
| Package weight |
62 kg |
| Package height |
1155 mm |
| Package depth |
225 mm |
| Package width |
1863 mm |
| Packaging content |
| Open Pluggable Specification (OPS) included |
Yes |
| Number of stylus pens |
2 |
| Stylus included |
Yes |
| Remote control included |
Yes |
| Batteries included |
Yes |
| Cables included |
AC, HDMI, USB |
| Manual |
Yes |
