Lenovo ThinkSystem SR630 V3 server Rack (1U) Intel® Pentium® 4410Y 1.5 GHz 64 GB DDR5-SDRAM 1100 W
- Intel Pentium 4410Y (2MB Cache, 1.5GHz)
- 64GB (4800MHz) DDR5-SDRAM (1 x 64)
The Lenovo ThinkSystem SR630 V3 is an ideal 2-socket 1U rack server for small businesses up to large enterprises that need industry-leading reliability, management, and security, as well as maximizing performance and flexibility for future growth. The SR630 V3 is designed to handle a wide range of workloads, such as databases, virtualization and cloud computing, virtual desktop infrastructure (VDI), infrastructure security, systems management, enterprise applications, collaboration/email, streaming media, web, and HPC.
This product guide provides essential pre-sales information to understand the ThinkSystem SR630 V3 server, its key features and specifications, components and options, and configuration guidelines. This guide is intended for technical specialists, sales specialists, sales engineers, IT architects, and other IT professionals who want to learn more about the SR630 V3 and consider its use in IT solutions.
| Processor | |
|---|---|
| Maximum number of SMP processors | 2 |
| Number of processors installed | 1 |
| Processor cache | 2 MB |
| Processor cores | 2 |
| Processor frequency | 1.5 GHz |
| Processor model | 4410Y |
| Processor family | Intel® Pentium® |
| Processor manufacturer | Intel |
| Memory | |
|---|---|
| Maximum internal memory | 8.19 TB |
| Memory slots | 32x DIMM |
| ECC | Yes |
| Memory clock speed | 4800 MHz |
| Memory layout (slots x size) | 1 x 64 GB |
| Internal memory type | DDR5-SDRAM |
| Internal memory | 64 GB |
| Storage | |
|---|---|
| Optical drive type | No |
| Hot-swap | Yes |
| Supported RAID controllers | 9350-8i |
| RAID levels | 0, 1, 5, 6, 10, 50, 60 |
| RAID support | Yes |
| Graphics | |
|---|---|
| Maximum graphics card memory | 16 MB |
| On-board graphics card model | Intel® HD Graphics 615 |
| On-board graphics card family | Intel® HD Graphics |
| On-board graphics card | Yes |
| Ports & interfaces | |
|---|---|
| VGA (D-Sub) ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 |
| USB 2.0 ports quantity | 2 |
| Ethernet LAN (RJ-45) ports | 1 |
| Design | |
|---|---|
| Chassis type | Rack (1U) |
| Performance | |
|---|---|
| Trusted Platform Module (TPM) | Yes |
| Trusted Platform Module (TPM) version | 2.0 |
| Performance management | XClarity Controller 2 |
| Software | |
|---|---|
| Compatible operating systems | Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware ESXi, Ubuntu Server |
| Power | |
|---|---|
| Number of redundant power supplies supported | 2 |
| Power supply | 1100 W |
| Redundant power supply (RPS) support | Yes |
| General | |
|---|---|
| Product family | ThinkSystem |
| Weight & dimensions | |
|---|---|
| Depth | 773 mm |
| Height | 43 mm |
| Width | 440 mm |
