Lenovo ThinkSystem 5300 960 GB 3.5″ Serial ATA III 3D TLC NAND
- 960 GB 3.5″ Serial ATA III
- Read speed: 540 MB/s 95000 IOPS
- Write speed: 520 MB/s 35000 IOPS
- 3D TLC NAND
- Component for: Server/workstation
The 5300 Entry SATA solid-state drives (SSDs) are new SSDs for ThinkSystem servers. The drives use Micron 96-layer 3D NAND flash memory technology with a SATA 6Gbps interface and provide an affordable solution for read-intensive applications such as boot, web servers, lower data rate operational databases and analytics.
| Features | |
|---|---|
| Mean time between failures (MTBF) | 3000000 h |
| Hot-swap | Yes |
| Write latency | 100 µs |
| Read latency | 175 µs |
| Random write (4KB) | 35000 IOPS |
| Random read (4KB) | 95000 IOPS |
| Write speed | 520 MB/s |
| Read speed | 540 MB/s |
| Data transfer rate | 6 Gbit/s |
| Component for | Server/workstation |
| Memory type | 3D TLC NAND |
| Interface | Serial ATA III |
| SSD form factor | 3.5″ |
| SSD capacity | 960 GB |
| Power | |
|---|---|
| Power consumption (write) | 3.4 W |
| Power consumption (read) | 2.8 W |
| Weight & dimensions | |
|---|---|
| Weight | 70 g |
| Operational conditions | |
|---|---|
| Non-operating shock | 1.5 G |
| Logistics data | |
|---|---|
| Harmonized System (HS) code | 84717070 |
