Lenovo Intel Xeon Bronze 3106 processor 1.7 GHz 11 MB L3
- Intel Xeon Bronze 3106 1.7 GHz
- 11 MB L3 LGA 3647 (Socket P)
- Processor cores: 8 14 nm 64-bit 85 W
- Maximum internal memory supported by processor: 768 GB DDR4-SDRAM
The ST550 supports the Bronze, Silver, Gold, and Platinum level processors in the Intel Xeon Processor Scalable Family.
| Processor |
| Processor codename |
Skylake |
| Thermal Design Power (TDP) |
85 W |
| Processor cache type |
L3 |
| Processor cache |
11 MB |
| Processor operating modes |
64-bit |
| Processor threads |
8 |
| Component for |
Server/workstation |
| Processor lithography |
14 nm |
| Processor socket |
LGA 3647 (Socket P) |
| Processor cores |
8 |
| Processor base frequency |
1.7 GHz |
| Processor model |
3106 |
| Processor generation |
1st Generation Intel® Xeon® Scalable |
| Processor family |
Intel Xeon Bronze |
| Memory |
| ECC |
Yes |
| Memory channels |
Hexa-channel |
| Memory clock speeds supported by processor |
2133 MHz |
| Memory types supported by processor |
DDR4-SDRAM |
| Maximum internal memory supported by processor |
768 GB |
| Graphics |
| On-board graphics card |
No |
| Features |
| Scalability |
2S |
| Embedded options available |
Yes |
| PCI Express slots version |
3.0 |
| Maximum number of PCI Express lanes |
48 |
| Market segment |
Server |
| Processor special features |
| Intel 64 |
Yes |
| Intel Virtualization Technology (VT-x) |
Yes |
| Intel TSX-NI |
Yes |
| Intel Turbo Boost Max Technology 3.0 |
No |
| Intel® Optane™ Memory Ready |
No |
| Intel® vPro™ Platform Eligibility |
Yes |
| Conflict-Free processor |
Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) |
No |
| Intel® Turbo Boost Technology |
No |
| Intel® AES New Instructions (Intel® AES-NI) |
Yes |
| Intel Trusted Execution Technology |
Yes |
| Intel® Speed Shift Technology |
Yes |
| Operational conditions |
| Tcase |
77 °C |
| Weight & dimensions |
| Processor package size |
76 x 56.5 mm |
| Other features |
| Compatibility |
Lenovo ThinkSystem ST550 |
