Lenovo 01CV830 network card Internal Fiber 16000 Mbit/s
- Wired
- PCIe 3.0 Fiber
- 16000 Mbit/s
- Internal Component for: Server
The Emulex 16 Gb (Generation 6) Fibre Channel (FC) host bus adapters (HBAs) are an ideal solution for all Lenovo System x servers requiring high-speed data transfer in storage connectivity for virtualized environments, data backup, and mission-critical applications. They are designed to meet the needs of modern networked storage systems that utilize high performance and low latency solid state storage drives for caching and persistent storage as well as hard disk drive arrays.
The Emulex 16 Gb Gen 6 FC HBAs feature ExpressLane™, which prioritizes mission-critical traffic in congested networks ensuring maximum application performance on flash storage arrays. They also seamlessly support Brocade ClearLink™ diagnostics through Emulex OneCommand® Manager, ensuring the reliability and management of storage network when connected to Brocade Gen 5 FC SAN fabrics.
| Ports & interfaces | |
|---|---|
| PCI version | 3.0 |
| Fiber ports quantity | 1 |
| Fiber optic connector | FC, SFP+ |
| Interface | Fiber |
| Host interface | PCIe |
| Connectivity technology | Wired |
| Network | |
|---|---|
| Maximum operating distance | 150 m |
| Web-based management | Yes |
| Full duplex | Yes |
| Maximum data transfer rate | 16000 Mbit/s |
| Design | |
|---|---|
| Compatible products | System x3500 M5 Type 5464System x3550 M5 Type 5463System x3550 M5 Type 8869System x3650 M5 Type 5462System x3650 M5 Type 8871System x3750 M4 Type 8753System x3850 X6 Type 6241 (E7 v2, E7 v3, and E7 v4)System x3950 X6 Type 6241 (E7 v2, E7 v3, and E7 v4)NeXtScale nx360 M5 Type 5465 (E5-2600 v3 and E5-2600 v4) |
| Certification | AS/NZS CISPR22:2009+A1, Class AAustralian EMC Framework (RCM)cUR recognized to CSA 22.2, No. 60950-1-07EN55022:2010, Class AEN55024:2010EN55032:2012EU (CE Mark)FCC Rules, Part 15, Class AIndustry Canada, ICES-003, Class AJapan VCCI, Class AKorea MSIP, Class ARoHS Compliant (Directive 2011/65/EU)TUV certified to EN60950-1+A11+A1+A12+A2Taiwan BSMI, Class AUL recognized to UL60950-1 2nd Edition |
| Mean time between failures (MTBF) | 10000000 h |
| LED indicators | Yes |
| Hot-swap | Yes |
| Hot-Plug support | Yes |
| Rack mounting | Yes |
| Rack capacity | 2U |
| Product colour | Black, Green, Silver |
| Component for | Server |
| Internal | Yes |
| System requirements | |
|---|---|
| Server operating systems supported | Windows Server 2012, Windows Server 2012 R2 |
| Other operating systems supported | VMware vSphere ESXi |
| Linux operating systems supported | RedHat EL Linux 6.0, RedHat EL Linux 7.0, SuSE Linux 11, SuSE Linux 12.0 |
| Operational conditions | |
|---|---|
| Operating relative humidity (H-H) | 5 – 95% |
| Storage temperature (T-T) | -20 – 85 °C |
| Operating temperature (T-T) | 0 – 55 °C |
| Weight & dimensions | |
|---|---|
| Height | 69 mm |
| Depth | 168 mm |
| Packaging data | |
|---|---|
| Package type | Box |
| Low-profile bracket | Yes |
| Quantity | 1 |
| Packaging content | |
|---|---|
| Mounting brackets included | Yes |
| Technical details | |
|---|---|
| Compliance certificates | RoHS |
| Logistics data | |
|---|---|
| Harmonized System (HS) code | 85176990 |
| Other features | |
|---|---|
| PCI-SIG* SR-IOV Capable | Yes |
