Epson C11CJ11401A0 dot matrix printer 10 cps
- Affordable: Cost effective alternative to other passbook printers
- Fast performance: Prints up to 540 characters per second with 6+1 copies
- Reliable: Significantly increased mean time between failure rate of 35,000 hours
- Compatible consumables: Same long-lasting ribbons compatible with all models
- Design: Improved, modern design
A 24-pin dot matrix passbook printer, designed as an economic solution, offering reliability, as well as fast printing and a modern design.
The PLQ-35 is a dot matrix printer that is affordable, ultra-reliable and has the capability to handle passbooks. The product is able to replicate previous emulations, which reduces the need for retraining.
When an economic solution is needed to replace existing passbook printers, the PLQ-35 is the ideal choice. With a 150% improved mean time between failures of 35,000 hours and reliable dot matrix technology, you can depend on these printers to deliver high-quality output with minimal intervention.
In addition, when time is of the essence, the PLQ-35 delivers fast printing of up to 540 characters per second (High-Speed-Draft, 10cpi), utilising 24-pins and 94 columns. Additionally, up to 6 copies can be produced simultaneously with the original.
The printer’s performance is matched by its cost-effectiveness. The ribbon is compatible across all of the Epson Passbook range and represents a budget friendly printing solution. Keep costs of business down, while keeping inline with current demands for CSR and organisational waste.
Printing | |
---|---|
Number of characters | 14 |
Character sets | ISO 8859-15, Italic, PC437, PC708, PC720, PC850, PC858, PC864, PCAPTEC, PCAR864, Roman 8 |
Bitmap fonts | Courier, Draft, OCR-B, Orator, Orator-S, Prestige, Roman, Sans Serif, Script, Script C |
Built-in barcodes | CODABAR (NW-7), Code-128 Codabar Library, Code-39 Library, EAN13, EAN8, Industrial 2/5, Interleaved 2/5, Matrix 2/5, POSTNET, UPC-A, UPC-E |
Maximum number of copies | 6 copies |
Character pitch | 10,12,15 cpi |
Normal print speed | 10 cps |
Maximum print speed (NLQ) | 10 cps |
Maximum print speed (LQ) | 10 cps |
Maximum print speed (draft) | 10 cps |
Maximum print speed | 10 cps |
Maximum printing width (columns) | 94 |
Paper handling | |
---|---|
Single sheet thickness range | 0.065 – 0.19 mm |
Multi-part paper thickness range | 0.12 – 0.53 mm |
Features | |
---|---|
Sound pressure level (quiet mode) | 52 dB |
Sound pressure level (printing) | 55 dB |
Buffer size | 128 KB |
Ports & interfaces | |
---|---|
Optional connectivity | Serial (RS-232) |
Standard interfaces | RS-232, USB |
Endurance | |
---|---|
Mean time between failures (MTBF) | 35000 h |
Print head life | 400 million characters |
Print head | 24-pin |
Power | |
---|---|
AC input frequency | 50 – 60 Hz |
Power consumption (standby) | 0.7 W |
AC input voltage | 220 – 240 V |
Power consumption (typical) | 61 W |
Operational conditions | |
---|---|
Operating relative humidity (H-H) | 10 – 85% |
Operating temperature (T-T) | 5 – 38 °C |
Weight & dimensions | |
---|---|
Weight | 7.8 kg |
Height | 203 mm |
Depth | 280 mm |
Width | 384 mm |
