DELL Xeon 4210R processor 2.4 GHz 13.75 MB
- Intel Xeon Silver 4210R 2.4 GHz
- 13.75 MB LGA 3647 (Socket P)
- Processor cores: 10 14 nm 64-bit 100 W
- Maximum internal memory supported by processor: 1.02 TB DDR4-SDRAM
The Intel Xeon® 4210R 2.4GHz Ten Core Processor enhances the performance and the speed of your system. Additionally, the Virtualization Technology enables migration of more environments. It supports enhanced SpeedStep® technology that allows tradeoffs to be made between performance and power consumption.
Its Thermal Monitoring Technologies protect the processor package and the system from thermal failure through several thermal management features. The VT-x with Extended Page Tables (EPT) also known as Second Level Address Translation (SLAT), provides acceleration for memory intensive virtualized applications. Packed with more features, the Xeon 4210R 2.4GHz Ten Core Processor is the ideal choice for virtually all of your data demanding or standard enterprise infrastructure applications.
This product is compatible with the following systems:
– PowerEdge T640
– PowerEdge R540
– PowerEdge R440
– PowerEdge C6420
– PowerEdge R740xd2
– PowerEdge R740XD
– PowerEdge T440
– PowerEdge FC640
– PowerEdge M640 VRTX
– PowerEdge MX740C
– PowerEdge R640
– PowerEdge M640
– PowerEdge R740
| Processor |
| Processor ARK ID |
197098 |
| Processor codename |
Cascade Lake |
| Thermal Design Power (TDP) |
100 W |
| Processor cache |
13.75 MB |
| Processor boost frequency |
3.2 GHz |
| Processor operating modes |
64-bit |
| Processor threads |
20 |
| Component for |
Server/workstation |
| Cooler included |
No |
| Processor lithography |
14 nm |
| Processor socket |
LGA 3647 (Socket P) |
| Processor cores |
10 |
| Processor base frequency |
2.4 GHz |
| Processor model |
4210R |
| Processor generation |
2nd Generation Intel® Xeon® Scalable |
| Processor family |
Intel Xeon Silver |
| Processor manufacturer |
Intel |
| Memory |
| ECC |
Yes |
| Memory channels |
Hexa-channel |
| Memory clock speeds supported by processor |
2400 MHz |
| Memory types supported by processor |
DDR4-SDRAM |
| Maximum internal memory supported by processor |
1.02 TB |
| Graphics |
| Discrete graphics card model |
Not available |
| On-board graphics card model |
Not available |
| On-board graphics card |
No |
| Discrete graphics card |
No |
| Features |
| Scalability |
2S |
| Embedded options available |
Yes |
| PCI Express CEM revision |
3.0 |
| Supported instruction sets |
SSE4.2, AVX, AVX 2.0, AVX-512 |
| PCI Express slots version |
3.0 |
| Maximum number of PCI Express lanes |
48 |
| Market segment |
Server |
| Execute Disable Bit |
Yes |
| Processor special features |
| Intel VT-x with Extended Page Tables (EPT) |
Yes |
| Intel 64 |
Yes |
| Intel Virtualization Technology (VT-x) |
Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) |
Yes |
| AVX-512 Fused Multiply-Add (FMA) units |
1 |
| Intel® Deep Learning Boost (Intel® DL Boost) on CPU |
Yes |
| Intel® Volume Management Device (VMD) |
Yes |
| Intel® Optane™ DC Persistent Memory Supported |
No |
| Intel® Speed Select Technology – Base Frequency (Intel® SST-BF) |
No |
| Intel® Speed Select technology – Performance Profile (Intel® SST-PP) |
No |
| Intel Turbo Boost Max Technology 3.0 |
No |
| Intel® vPro™ Platform Eligibility |
Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) |
Yes |
| Intel® Turbo Boost Technology |
2.0 |
| Intel® AES New Instructions (Intel® AES-NI) |
Yes |
| Intel Trusted Execution Technology |
Yes |
| Intel® Speed Shift Technology |
Yes |
| Enhanced Intel SpeedStep Technology |
Yes |
| Operational conditions |
| Tcase |
84 °C |
| General |
| Product family |
Xeon |
| Logistics data |
| Harmonized System (HS) code |
85423119 |
| Weight & dimensions |
| Processor package size |
76.0 x 56.5 mm |
