Cisco Intel Xeon Gold 5418Y processor 2 GHz 45 MB Box
- Intel® Xeon® Gold 5418Y 2 GHz
- 45 MB LGA 4677 (Socket E)
- Processor cores: 24 64-bit 185 W
- Maximum internal memory supported by processor: 6 TB DDR5-SDRAM
- Box
The Xeon® Processor from Cisco is designed to deliver enhanced reliability and flexibility for server platforms. This processor offers excellent performance and headroom for peak Internet server loads, resulting in faster response times, support for more users and improved scalability.
| Processor | |
|---|---|
| Processor ARK ID | 232379 |
| Processor codename | Sapphire Rapids |
| Stepping | S3 |
| Thermal Design Power (TDP) | 185 W |
| Processor cache | 45 MB |
| Low priority cores | 16 |
| High priority core frequency | 2.2 GHz |
| High priority cores | 8 |
| Processor boost frequency | 3.8 GHz |
| Processor operating modes | 64-bit |
| System bus rate | 16 GT/s |
| Processor threads | 48 |
| Processor series | Intel Xeon Gold 5000 Series |
| Cooler included | No |
| Box | Yes |
| Processor socket | LGA 4677 (Socket E) |
| Processor cores | 24 |
| Processor base frequency | 2 GHz |
| Processor model | 5418Y |
| Processor generation | Intel Xeon Scalable 4th Gen |
| Processor family | Intel® Xeon® Gold |
| Processor manufacturer | Intel |
| Memory | |
|---|---|
| ECC | Yes |
| Memory channels | Octa-channel |
| Memory types supported by processor | DDR5-SDRAM |
| Maximum internal memory supported by processor | 6 TB |
| Graphics | |
|---|---|
| Discrete graphics card model | Not available |
| On-board graphics card model | Not available |
| On-board graphics card | No |
| Discrete graphics card | No |
| Features | |
|---|---|
| Commodity Classification Automated Tracking System (CCATS) | G180729 |
| Export Control Classification Number (ECCN) | 5A992C |
| Scalability | 2S |
| Embedded options available | Yes |
| Supported instruction sets | AMX, SSE4.2, AVX, AVX 2.0, AVX-512 |
| PCI Express slots version | 5.0 |
| Maximum number of PCI Express lanes | 80 |
| Use conditions | Server/Enterprise |
| Market segment | Server |
| Execute Disable Bit | Yes |
| Processor special features | |
|---|---|
| Intel® Advanced Matrix Extensions (AMX) | Yes |
| Intel® Data Streaming Accelerator (DSA) | 1 default devices |
| Intel® On Demand Feature Activation | Yes |
| Intel® QuickAssist Software Acceleration | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel Software Guard Extensions (Intel SGX) | Yes |
| Intel 64 | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| AVX-512 Fused Multiply-Add (FMA) units | 2 |
| Intel® Deep Learning Boost (Intel® DL Boost) on CPU | Yes |
| Intel® Resource Director Technology (Intel® RDT) | Yes |
| Mode-based Execute Control (MBE) | Yes |
| Intel® Optane™ DC Persistent Memory Supported | Yes |
| Intel® Speed Select Technology – Base Frequency (Intel® SST-BF) | Yes |
| Intel® OS Guard | Yes |
| Intel® Speed Select technology – Performance Profile (Intel® SST-PP) | Yes |
| Intel® Run Sure Technology | Yes |
| Intel® Boot Guard | Yes |
| Intel® Crypto Acceleration | Yes |
| Intel® Platform Firmware Resilience Support | Yes |
| Maximum Enclave Size Support for Intel® SGX | 128 GB |
| Intel® Control-flow Enforcement Technology (CET) | Yes |
| Intel® Total Memory Encryption | Yes |
| Intel® Transactional Synchronization Extensions | Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel® Turbo Boost Technology | 2.0 |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel Trusted Execution Technology | Yes |
| Intel® Speed Shift Technology | Yes |
| Operational conditions | |
|---|---|
| Tcase | 81 °C |
| DTS Max | 94 °C |
| Logistics data | |
|---|---|
| Harmonized System (HS) code | 8542310001 |
| Technical details | |
|---|---|
| Launch date | Q1’23 |
| Status | Launched |
| Memory speed (max) | 4400 MHz |
| Number of UPI links | 3 |
| Supported memory types | DDR5-SDRAM |
| Package carrier | E1B |
| Packaging data | |
|---|---|
| Package type | Retail box |
| Weight & dimensions | |
|---|---|
| Processor package size | 77.5 x 56.5 mm |
| Other features | |
|---|---|
| Maximum internal memory | 4 TB |
