Axis 02044-001 network splitter Power over Ethernet (PoE) Black
- IEEE 802.3af; Plug-and-play; Reduced installation costs
A splitter is used to split the power and data in an Ethernet cable into two separate cables, which then can be connected to a network device that has no built-in support for Power over Ethernet (PoE). The PoE Splitter 5 V is IEEE 802.3af compliant and can be powered from any Axis midspan or PoE switch. The splitter is easily installed, with no need for system reconfiguration.
| Features | |
|---|---|
| Plug and Play | Yes |
| Cable length | 0.3 m |
| Product colour | Black |
| Power over Ethernet (PoE) | Yes |
| Networking standards | IEEE 802.3af |
| Ports & interfaces | |
|---|---|
| Ethernet LAN (RJ-45) ports | 2 |
| Operational conditions | |
|---|---|
| Operating temperature (T-T) | 0 – 40 °C |
| Storage temperature (T-T) | -25 – 65 °C |
| Certificates | |
|---|---|
| Certification | EN 55024, EN 55032 Class A, FCC Part 15 Subpart B Class A, ICES-3(A)/NMB-3(A), RCM AS/NZS CISPR 32 Class A |
| Weight & dimensions | |
|---|---|
| Weight | 100 g |
| Height | 28 mm |
| Depth | 100 mm |
| Width | 55 mm |
| Power | |
|---|---|
| Output current | 2.5 A |
| Output power | 12.5 W |
| Output voltage | 5 V |
