Axis 01996-001 wire connector RJ-45 Black, Metallic
- Easy to assemble; For CAT6a (AWG 26-22); MPTL compliant; Small form factor; Suitable for PoE
RJ45 Field Connector is easy to assemble and thanks to its compact size, it’s ideal for terminating CAT6a cables directly in a wide range of Axis network devices. The connector is compliant with the latest standard ANSI/TIA-568.2-D, which allows MPTL-installations (modular plug terminated link). It’s suitable for IEEE 802.3af, 802.3at and 802.3bt. The connector is sold in packages of 10.
| Features | |
|---|---|
| Certification | ANSI/TIA-568.2-D, EN 60603-7-51, ISO/IEC 11801 Ed.2.2: 2011-06/ EN 50173-2: 2011-09, ISO/IEC 24702/ EN 50173-3: 2011-09, ISO/IEC 15018/ EN 50173-4: 2011-09 |
| AWG wire size | 22/26 |
| Cable standard | Cat5e/Cat6 |
| Material | Metal, Plastic |
| Product colour | Black, Metallic |
| Connector form factor | Straight |
| Connector gender | Male |
| Connector(s) | RJ-45 |
| Operational conditions | |
|---|---|
| Storage temperature (T-T) | -40 – 70 °C |
| Operating temperature (T-T) | -40 – 70 °C |
| Weight & dimensions | |
|---|---|
| Depth | 51.3 mm |
| Width | 12.9 mm |
| Height | 14.7 mm |
| Packaging data | |
|---|---|
| Quantity per pack | 10 pc(s) |
